Dual Channel NDIR CO2 Sensor Module
$5.40 ~ $8.40
Dual-channel NDIR CO2 sensor module, High Accuracy and Excellent Stability
- Certification
-
- Award
-
- Shipping
-
- Lead Time1 ~ 7days
- Type of Freight AT
- Modes of Transport EXW,FCA,FOB
- Products Shipped From Incheon
- Payment
-
140+ Global Payments, trusted and secure payment provided by PayVerse.
Learn More
- Quantity
- MOQ : 100 Pieces
Detailed Description
Dual-CH NDIR CO2 Sensor
‘Embedded digital detector made in Korea’
TES0902
1. Product Specifications
| Operating Temperature | -10 ~ 50℃ |
| Operating Humidity | 0 ~ 95% RH |
| Storage Temperature | -20 ~ 80℃ |
| Measuring Gas & Range | CO2 : 400 ~ 5,000ppm |
| Accuracy | ±(50ppm +3% of measured value) |
| Response Time | < 30 seconds (diffusion) |
| Warm-up Time | < 2 minutes |
| Power Supply Range | 5V |
| Average Consumption | < 25mA at 5V |
| Output Interface | UART, PWM |
| Lifetime | Minimum 10 years or 13,000h |
2. Features
1. High accuracy with dual-channel
2. Pre-calibrated and Ready-to-use
3. Low power consumption
3. Applications
1. HVAC (Heating, Ventilation, Air-conditioning)
2. Indoor air quality (IAQ) control
