RDF (Refuse Derived Fuel) Production Facility
The facility efficiently separates non-combustible materials such as metals and glass, removes moisture and organic components, and compresses high-calorific waste fractions into RDF format fuel.
The produced RDF can replace fossil fuels in cement kilns, industrial boilers, and waste-heat recovery power plants, significantly reducing carbon emissions and energy costs.
With experience in waste processing and mechanical plant engineering, DAEHAN E&C provides customized RDF production systems tailored to local waste characteristics and site requirements.
The facility features fully automated based operation, integrated dust collection, and odor control systems, ensuring safe, efficient, and eco-friendly performance.
- Certification
-
- Award
-
- Shipping
-
- Lead Time15 ~ 30days
- Type of Freight MT
- Modes of Transport Proceed after consultation
- Products Shipped From Dangjin,Incheon,Busan,Pyeongtaek
- Payment
-
140+ Global Payments, trusted and secure payment provided by PayVerse.
Learn More
- Quantity
- MOQ : 1 LOT
Product Summary
• Brand name: DAEHAN E&C Co., Ltd. / GENSYS
• Type: Fixed automatic RDF production line
• Condition: New production
• Size/Dimension: Customized
• Weight: Approximately 120–200 tons (varies depending on equipment configuration)
• Applicable Industries: Waste treatment facilities, cement plants, industrial boilers, power plants
• Warranty: 12-month free warranty
• Certification: CE, ISO 9001, ISO 14001, KC, and other separate certifications provided upon request
Detailed Description
Detailed Equipment Description of MSW RDF Production Facility
1. MSW Feeding and Weighing System
> Ensures uniform feeding of mixed municipal waste from collection trucks and performs initial weighing.
> Includes bunker, hopper, feeder, and automated weighing system.
2. Pre-treatment and Sorting System
> Separates metals, plastics, glass, and other non-combustibles using trommel screen, air separator, magnetic separator, and optical sorter.
> Enhances RDF quality by removing recyclable and inert materials.
3. Shredding System
> Consists of primary and secondary shredders, reducing waste to particles smaller than 50mm.
> Combines high-speed and low-speed shredders for both efficiency and durability.
4. (Optional) Drying System
> Rotary or belt dryers can be optionally applied to reduce the moisture content below 20 ~ 25%.
> Heat sources can include waste heat, biogas, or steam.
5. (Optional) RDF Pelletizing or Compaction System
> Compresses or pelletizes dried high-calorific waste into standardized RDF.
> Available in compactor, ring die, or flat die pelletizer types.
6. (Optional) Dust Collection and Odor Reduction System
> Includes bag filters, scrubbers, and activated carbon filters to control dust and odor, ensuring environmentally safe operation.
7. Automation-Based Control and Monitoring System
> Centralized control of the entire system with remote monitoring and real-time alerts.
> Supports automated operation and optimized energy usage.
