-Enterprise Wi-fi security support
-Support for the most complete sensor monitoring 365
-Send data to customer server
-OLED screen that does not freeze even at low temperature
-Waterproof and Dustproof design to ensure safety
-Brackets sensor waterproof with magnet
-Screw support menbrane filter

[ Features ]

1) High reliablility

     -Rear time data backup to micro SD card

     -FeRAM is 10 times faster and has 1 bilion times higher write endurance than flash memory

     -Data measured during internet loss time is stored on the device and automatically send to server upon restoration

2) Groundbreaking power management system      -3.6V (1EA) or 1.5V (2EA) optional available

     -Low battery watning notification      -5~30V DC power supply

     -Built-in UPS (automatically switched to bettaery in case of power failure)

 3) Various sensor support

     -Temp- sensor (NTSC, T/C, PT100)      -Temp- / RH sensor (Internal, External)     -Gas sensor (NH3, H2S)

     -Particle sensor ( PM0.5, PM2.5, PM10)      -Door magnet sensor

4) Output signals and Calibration

     -RS-485 (T2GS, T2PM, T2TS, T2CS)      -Dry contact ON/OFF Output (T2EX, H2EX)

     -Micro USB terminals for calibration (Dedicated software provide)

     [ Specifications ]

-Channel Info : CH1; Temp (Range -20~60deg, MEMS) / CH2; RH (Range 0~95% RH, MEMS)

-Accuracy : Temp; +-0.3deg (0~90deg) +-0.4deg (-20~0deg) / R.H; +-2.0%RH (10~90RH) / NTSC;-0.8deg (typical)

-Operation Condition : Temp; -20~60deg / R.H; 0~95%RH (Non condensing)

-Communication Method : 2.4GHz IEEE 802.11 b/g/n up to WPA2-Enterprise / HTTP; Get / Post (Radionode V2 protocol)

-Battery / Lifespan : C type 1.5V x 2EA or C type 3.6V x 1EA / a year with 1.5V x 2EA 10min sensing

                                           *Sleep; 36uW  *measuring; 84mW   *Wifi; 400mW

-Power (Option) / UPS : DC 5~30V / YES (When DC power Shutdown, the source is changed into the battery immediately)

-Protection : IP65           -Size : 100H x 165W x 50D mm (With cable, Gland total height is 115mm)
