• Product name : Sliding Balance Trainer
• Brand name : Man&Tel co., ltd
• Type : Rehabilitation Medical Equipment
• Model Number : MSBT-10
• Usage : This equipment is a manual function recovery apparatus, a trainer of strengthening muscle power of lower limb deteriorated its function and improving vertical balance ability through the patient ’s exercise repeating flexion and extension of lower limb and thus sliding his body up and down in the lying position safely on the bed
• Material : Metals and Alloys
• Size/Dimension : 800(W) x 2,040(L) x 730(H)mm
• Shelf Life : -
• Feature
 Reconstruction of muscle power and recovery of joint mobility ability.
 Application of difficulty levels by means of gravity (by bed tilting angle).
 Lower limb strength training safely while lying in bed
 Left and right selection training
 Both legs training
 Patient oriented active training
 Lower limb muscle power strengthening training
 Bending training and Vertical balance training
 Adjustable bed height
 Bed tilting angle: 0~40° ±5%
 Foothold tilting angle(Motor operated) : -12° ~ +12°
• Warranty : 1 year charge free warranty, 5 years with payment
• Certification
 KFDA Product category : Manually-operated rehabilitation exerciser
 KFDA Manufacturing Permission No. 3399
 Certificate of Free Sales
 KGMP Certificated
 ISO13485 Certificated
 FDA Registration Number: 3011806255
 FDA Listing No. D301901
 Korean Patent(No. 10-2042474)
 USA Patent: 7,744,546 B2(June 2010)

1. Usage

This equipment is a manual function recovery apparatus, a trainer of strengthening muscle power of lower limb deteriorated its function and improving vertical balance ability through the patient ’s exercise repeating flexion and extension of lower limb and thus sliding his body up and down in the lying position safely on the bed.

- Target patients: stroke, traumatic brain injury, spinal cord injury, cerebral palsy, elderly people, all patients with reduced motor skills

- Usage: lower limb muscle strengthening & motor control training, closed kinetic exercise, knee bending exercise, vertical balance training

- Exercise method: Lie down safely and slide the patient's body up and down by bending and straightening the patient's legs, adjusting the load by adjusting the angle of the bed.



2. Features

- Reconstruction of muscle power and recovery of joint mobility ability.

- Application of difficulty levels by means of gravity (by bed tilting angle).

- Lower limb strength training safely while lying in bed

- Left and right selection training

- Both legs training

- Patient oriented active training

- Lower limb muscle power strengthening training

- Bending training and Vertical balance training

- Adjustable bed height

- Bed tilting angle: 0~40° ±5%

- Foothold tilting angle(Motor operated) : -12° ~ +12°



3. Specification

- Equipment size: 800(W) X 2,040(L) X 730(H)mm

- Bed height: 570mm

- Required installation space: 1,200(W) X 2,200(L) X 1,750(H)mm

- Equipment weight: 110Kg

- Max. bearable weight of patient:120Kg

- Power/Power consumption: AC 220V, 50/60Hz / 230W

- Bed tilting angle: 0~40° ±5%

- Foothold tilting angle(Motor operated) : -12° ~ +12°

*Product specifications are subject to change without notice for product improvements



4. Composition

- Sliding bed(Head section mattress and back section mattress)

- Footholds

- Leg supporting rest

- Remote control unit(wired)

- Safety fixing belt

- Clamping pin

- Cylinder(1)

- Analog angle meter

- User manual



5. Others



- KFDA Product category : Manually-operated rehabilitation exerciser

- KFDA Manufacturing Permission No. 3399

- Certificate of Free Sales

- KGMP Certificated

- ISO13485 Certificated

- FDA Registration Number: 3011806255

- FDA Listing No. D301901

- Korean Patent(No. 10-2042474)

- USA Patent: 7,744,546 B2(June 2010)

- Warranty period: 1 year charge free warranty, 5 years with payment(1-year extension adds 5% of product price)
