1. Features

- Ultralight titanium alloy construction option available

- Remote monitoring signals for tank fuel level content and pressure.

- Patented pressure management system using electrical heater (24V)

- Adjustable setting pressure regulator for fuel cell inlet requirement

- Patented fueling receptacle and nozzle connection with seal-sealing shutoff valves.

2. Technical Data

- Gross Capacity : 630L

- Net Capacity : 570L

- Length : 700mm - Outside Diameter : 205mm

- Empty Weight : 2.8kg

- Liquid H2 Weight : 840g

- NER : 3.0% / day

- MAWP : 3bar

- Wt % : 20~25% wt

- Volume % : 40~45g / L

3. Options

- Accessories : External heat exchanger and vacuum jacketed transfer line
