Safety Air Cushion-octagonal Shape
Request For Quotation
SAFETY AIR CUSHION OCTAGONAL SHAPE - CYLINDER TYPE
Our Safety Air Cushion was safely rescued from a high building structure to be high or when a emergency Rescue situation and can also be used in firefighting training as long as the manufacturer's instruction are followed. Our Safety Air Cushion produced Waterproof, fire-retardant, anti-acid, highly tear and abrasion resistant material, guarantees an excellent level of reliability and strength. Our cushions that can be tailored to the size buyers demand from small size to large size and specially designed to be easily recognized structure in the midnight and dark area.
Our Safety Air Cushion was safely rescued from a high building structure to be high or when a emergency Rescue situation and can also be used in firefighting training as long as the manufacturer's instruction are followed. Our Safety Air Cushion produced Waterproof, fire-retardant, anti-acid, highly tear and abrasion resistant material, guarantees an excellent level of reliability and strength. Our cushions that can be tailored to the size buyers demand from small size to large size and specially designed to be easily recognized structure in the midnight and dark area.
- Certification
-
- Award
-
- Shipping
-
- Modes of Transport Proceed after consultation
- Payment
-
140+ Global Payments, trusted and secure payment provided by PayVerse.
Learn More
- Quantity
- MOQ : 1 SET
Product Summary
• Product name: Safety Cushion Octagonal Shape(Cylinder Type)
• Brand name: GSC GLOBAL SAFE CORPORATION
• Size/Dimension: Customization is available
• Material: Made from 100% special Polyester, fire resistance, waterproof, highly tearing resistance, have double seam structure, the cover can be mend able by special material.
• Brand name: GSC GLOBAL SAFE CORPORATION
• Size/Dimension: Customization is available
• Material: Made from 100% special Polyester, fire resistance, waterproof, highly tearing resistance, have double seam structure, the cover can be mend able by special material.
Detailed Description
↵
Features
- Cushion is installed by Compressed Air Cylinder.(Electric or Motor pump is not required.)
- Easy to install and to moving with 4 edge Handle while operation.
- Reinflation within 30 second (Depend on size) after landing.
- The big holes for 1~2 chambers of Air cushion are designed for immediate air injection and allow restoring cushion to the original state earlier after landing.
- Air Cushions consists of one or two chambers that allow you to land safely.
- Air Cushion fully absorb the kinetic energy from landing body and do not give back bounce.
- Structure:
- Cushion’s chambers are designed for immediate air injection and allow restoring to the original state easier after landing
- There are plastic handles bottomed on four sides of air cushion for making easy and convenient while moving in using.
- Material
- Made from 100% special Polyester, fire resistance, waterproof, highly tearing resistance, have double seam structure, the cover can be mend able by special material.
- Luminous Lines are easy to fall down when the environment is dark.
Material
- Tube: 1100 denier polyester coated with plastomer having excellent resistance to tearing, tension and breaking.
- Cover: 1100 denier polyester coated with fire retardant and water-proof.
Tested
ISO 9001:2008 EN ISO6941 DIN EN 20811 DIN EN ISO 13938-1:999 BS5438 DIN 14151-3. DIN 53354:1981 DIN 4102 B1 DIN 53352 DIN 53353 DIN 53363 DIN 53886 DIN 53361 NFPA 701,M2,CL2,LSG
Specifications
| MODEL | GOC-035 | GOC-037 | GOC—0552 | GOC-0963 |
| (DC-60S) | ||||
| No.of Chamber | One Chamber | One Chamber /Two Chamber | ||
| Size(m) | 3.5x3.5x1.7 | 3.7x3.7x1.7 | 5.5x5.5x2.0 | 9.6x9.6x3.0 |
| Allowable Height | Under 15M | Under 16M | 30M | 45M |
| No.of Cylinder | Composite.6.8L x 1or 2 | Composite.6.8L x 2 | ||
| Inflation time | 55sec | 60sec | 75sec | 90sec |
| Reflation time | 10sec | 10sec | 10sec | 30sec |
| Cushion Weight | 62kg | 65kg | 105kg | 250kg |
| Packing(cm) | 130x70x50 | 130x70x50 | 130x75x50 | 130x80x55 |
+Due to Customized product, we can change the size, material, etc. and the model number can be added.
[Example] MODEL: GOC-0552HY
Material of Frame can be changed to polyamid yarn with natural rubber reinforcement(Neoprene, Hypalon).
