Model:H81FHL

System:
Processor Support:Supports Intel Core/i5/i7 Serials processors in LGA1150 package.Support Intel 4th Gen multi-core processors

Chipset:Intel® H81 Chipset

Memory Support:DDR3 1600/1333 SDRAM2 DDR3 DIMMs (240 pin/ 1.5V)

_{(on compatible components, please check with manufacturer)}

LAN:Onboard Realtek® 10/100Mbps LAN(1000M Optional)

Audio:Chip integrated by Realtek®662 Flexible 6-channel

SATA:4 SATA 3 ports Supports storage and transfers up to 6Gbps

Back panel:

• 1 VGA port
• 1 HDMI port
• 2 USB 3.0 Ports
• 4 USB 2.0 Ports
• 1 LAN jack
• 3 flexible audio jacks

On-Board Pinheaders / Connectors

• 1 USB 3.0 pinheader
• 1 USB 2.0 pinheader
• 1 Front Panel pinheader

Slots:1 PCI Express x16 slot

Form Factor:Micro-ATX (19 cm X 17 cm), Mounting:6 mounting holes, Accessories:

• 4-pin SATA power cable/SATA data cable (optional)
• 1X I/O Backboard
• 1X User Manual
• 1X Drives installed CD

All Mainboards are fully tested like Sound,Vga,Lan,Ram Slots,Windows tested

G31.G41,H55,H61,P67,H81,B75,B85,H110,B150,B250,H310.H410,H360,Z370 ETC
