Detailed Description
Feature
· Flexible silicon tube housing
· High light transmittance with plane light
Applications
· Edge lighting
· Showcase and furniture lighting
· Decorative or ornamental lighting
■ Electrical-Photometrical Specification
|
| LILAC-S6 | LILAC-S10 |
| Color | W.White / C.White | |
| Luminous Flux | 433.9lm/m | 500lm/m |
| Light Distribution Angle | 180˚ | 120˚ |
| Number of LEDs | 96 ~ 126 | 196 |
| Input Voltage | DC 24V | |
| Power | 10 ~ 14W | 14W |
| Operating Temp. | -20~+70℃ | |
■ Mechanical Specification
|
| LILAC-S6 | LILAC-S10 |
| Housing | Silicon tube | |
| Lens Cover | Milky color silicon tube | |
| Size | W6 x H12mm | W10 x H10mm |
| PCB Increment | 82mm (L=310~5,000mm) | 35mm(L=310~5,000mm) |
| Protection Class | IP 65 | |
| Mounting | 3M adhesive tape | |
| Connection | Wire or connectors | |
■ Ordering Option in Detail
| Color Temp. | 2,700~4,000°K / 5,000~10,000°K |
| CRI | 80 / 90 / 97 |
