Features

Solenoid valves are operated by electromagnetic force once electric supply is put into the coil.

It is used for controlling the industrial automation and safety system,

There are various models depending on the process pressure applied.

Passed Waterproof test standard IEC 60529:2001 ( IP68 )

Since diaphragm and plunger are linked with each other mechanically,

the machine can work at differential pressure "0", not depending on any pressure.

Maximized amount of fluid to the diaphragm mode.

Convenient maintenance due to fewer parts.

The waving type coils can be freely to the wiring direction.

Applications

Water/Air distributed pipes, Fountain, Industrial cleaning machines, Compressors,

Water filters, Welders, Packing machines, Heavy equipments,

Heating and ventilation systems, Medical equipments, Boilers, etc.

Specifications

Working Fluid : Water, Air, Oil

Working Pressure : 0.3 ~ 10bar

Voltage : AC 220V, AC110V, DC 24V, DC 12V

Coil Insulation : Class F

Length of Lead wire : 500~1000 mm

Fluid Temperature : 0 ~ 60 °C

Seat Material : NBR
