Check Scanner WiseScan120
Request For Quotation
Single feed Check Scanner with UV scan
- Certification
-
- Award
-
- Shipping
-
- Modes of Transport EXW
- Payment
-
140+ Global Payments, trusted and secure payment provided by PayVerse.
Learn More
- Quantity
- MOQ : 1 Sets
Detailed Description
FEATURES
WiseScan120 is a horizontal type single feed cheque scanner.
WiseScan120 scans one object at a time with a speed at 125mm/sec under 200dpi color setting.
The built-in MICR reader recognizes E13B and CMC7 on cheques and other securities.
WiseScan120 provides three scanning modes: 24 bit color, gray scale and B/W. UV light mode is an option to enhance security to prevent fraud cheque transactions.
SPECIFICATIONS
| Item | Specification |
| Document | |
| Height | 54~106mm |
| Length | 80~235mm |
| Weight | 60~120g/m2 |
| Scanner | |
| Scanning Side | Duplex |
| Sensor | Color CIS |
| Scan width | 104mm |
| Resolution | 200/300dpi |
| Color | 8bit Grey, 1bit B/W, 24bit True Color, UV image (option) |
| Illumination | R(620nm), G(525nm), B(464nm), UV(375nm) |
| Image Formats | TIFF G4, JPEG, BMP |
| Processing Speed | 125mm/sec with 200dpi color scan setting |
| MICR Reader | |
| Recognize codes | E13B and CMC7 |
| Read Head | Magnetic head with permanent magnet excitation |
| Interface | |
| Type | USB 2.0 High Speed (480Mbps) |
| Physical Dimensions | |
| Size | 155mm(W) x223mm(D) x85mm(H) |
| Weight | 1.1 kg |
| Power | |
| Adapter Input | AC 100~240V, 50~60Hz, 1.75A |
| Adapter Output | DC 24V/1.2A |
| Environment | |
| Operating temperature | 5~45°C |
| Operating Humidity | 10 ~ 85%, Non condensing |
