Ultrasonic Water Bath

DSsono-1001

The bony bumps and irregularly shaped areas such as the hand, wrist, ankle and foot are often difficult to treat with the ultrasound applicator in direct contact.

Water immersion ultrasound is ideal for these smaller areas and DSsono makes this subaqueous treatment far more convenient and effective.

DSsono gives both patient and clinician much freedom and safety through enabling patients themselves to treat their injured parts simply with the clinician's instructions, while the conventional underwater ultrasound has only been administered with the clinician who submerges the sound head and holds it approx. 1cm away from the patients skin surface.

DSsono's two 30kHz transducers inserted in the basin intensively target the treatment area.

DSsono also gives cost saving on consumables by using water as a coupling medium, not necessarily using gel or paraffin.

Underwater ultrasound with DSsono is a effective modality for the smaller areas especially the hand, wrist, feet, heel, Plantar Fasciitis and Tennis Elbow that are difficult to use direct contact ultrasound.

Features

- Desired to treat more effectively the irregular body parts

- Minimizes the inconvenience of the conventional water bath ultrasound

- Enables patients to adjust their affected body parts themselves, which makes the treatment safer.

- Simple and convenient operation.

- Savings on consumables by using water as a couplant

Specifications

Power supply AC 220V, 60Hz

Power consumption 220VA

Ultrasound frequency 30kHz

Ultrasound intensity ≤1.28W/㎠

Class of protection : 1, Type BF

Time of therapy : 1-30 minutes(Initial setting time is 5 min)

Temperature max : 38°C

Dimensions : 240*460*280(W*D*H)

Weight : 9.4kg

Country of Manufacture: South Korea
