Characteristics
- When indoor temperature is above 27 degrees, the environment can be comfortable by separating and installing Cooler outside.
- For the place of no Ventilation, Less production, and higher heat, separated one is suitable.
- It provides us with deliberate temperature and wide range of temperature from 15 degrees to 25
degrees by touching only once.
- In terms of simple design and compact size, It is possible to install in the small places

Purpose of use : For Sauna’s cold water



Standard Specification



	DH-5AMS	DH-7.5AMS	DH-10AMS	DH-15AMS	DH-20AMS
Dimensions (LxWxH)	1,000x600x750	1,350x750x750	1,350x750x750	1,600x900x900	2,070x900x900
Dimensions (LxWxH)	925x855x1,023	1,346x800x816	1,346x800x816	1,576x900x912	1,600x950x1,010
Compressor OutPut (kW)	3.75	5.5	7.5	11.25	15
Cooling Capacitgy (Kcal/hr)	12,000	18,000	25,000	37,000	50,000
Circulation Pump (kW)	NONE
Flow Volume (l/min)	NONE
Water TnakCapacity(l)	NONE
Evaporator	Shell And Tube Type (STS 304)
Total Power Consumption (kW/h)	4.15	6.35	8.3	12.25	16.5
Power(V)	3PH 220/380/440V 50/60Hz

All the details can be changed without any notice with the products developed.
