FORGED FITTINGS, WROUGHT FITTINGS, SPECIAL FITTINGS
- Award
-
- Shipping
-
- Payment
-
140+ Global Payments, trusted and secure payment provided by PayVerse.
Learn More
Detailed Description
Product Detail Information
Pressures : 2000LB / 3000LB / 6000LB / 9000LB
End Connections : Threaded / Socket Weld
Size for :
Laterals, Bushings and Plugs & Pressure Fittings : 1/8” – 4”
90° LR Elbows, 90° Reducing Elbows, 45° Elbows, Tees, Reducing Tees, Concentric Reducers, Eccentric Reducers, Caps, Stub Ends, Crosses, Reducing Crosses, 180° LR Return Bends, 180° SR Return Bends, Laterals, Weldolets, Stub Ends, Swage Nipples, Nipples, Couplings, Weld Ring & Saddles : 1/8” – 36”
Nipples, Swages, Outlets : All Sizes
Pressure Fittings :
90° Elbows, 45° Elbows, Street Elbows, Tees, Crosses, Couplings, Reducers, Inserts, Caps, Unions
Special sizes and specifications other than above can be manufactured on request.
Chrome Fittings
|
Grade |
Pipe |
Tube |
Fittings |
Bar |
Forgings |
|
Cr-Mo Grade P-1 |
A335 P1 |
A231 T1 |
A234 WP1 |
A387 Grade 1 |
A182 F1 |
|
Cr-Mo Grade 5 |
A335 P5 |
A231 T5 |
A234 WP5 |
A387 Grade 5 |
A182 F5 |
|
Cr-Mo Grade 9 |
A335 P9 |
A231 T9 |
A234 WP9 |
A387 Grade 9 |
A182 F9 |
|
Cr-Mo Grade 11 |
A335 P11 |
A231 T11 |
A234 WP11 |
A387 Grade 11 |
A182 F11 |
|
Cr-Mo Grade 22 |
A335 P22 |
A231 T22 |
A234 WP22 |
A387 Grade 22 |
A182 F22 |
|
Cr-Mo Grade 91 |
A335 P91 |
A231 T91 |
A234 WP91 |
A387 Grade 91 |
A182 F91 |
Seamless Steel Fittings
|
Grade |
Pipe |
Tube |
Fittings |
Plate |
Bar |
Forgings |
UNS No. |
|
Stainless 304 |
A312 |
A213/249/269 |
A403 |
A2240 |
A276/479 |
A182 |
S30400 |
|
Stainless 309 |
A312 |
A213/249/269 |
A403 |
A2240 |
A276/479 |
A182 |
S30900 |
|
Stainless 310 |
A312 |
A213/249/269 |
A403 |
A2240 |
A276/479 |
A182 |
S31000 |
|
Stainless 316 |
A312 |
A213/249/269 |
A403 |
A2240 |
A276/479 |
A182 |
S31600 |
|
Stainless 317 |
A312 |
A213/249/269 |
A403 |
A2240 |
A276/479 |
A182 |
S31700 |
|
Stainless 321 |
A312 |
A213/249/269 |
A403 |
A2240 |
A276/479 |
A182 |
S32100 |
|
Stainless 347 |
A312 |
A213/249/269 |
A403 |
A2240 |
A276/479 |
A182 |
S34700 |
|
Stainless 410 |
A268 |
A213/249/269 |
A815 |
A2240 |
A276/479 |
A182 |
S41000 |
Low Temperature Fittings
|
Grade |
Pipe |
Tube |
Fittings |
Flanges |
Bar |
Forgings |
|
Low Temp C.S Grade 1 |
A333 Grade 1 |
A334 Grade 1 |
A420 WPL1/6 |
A350 LF2 |
A516 |
A350 LF2 |
|
Low Temp C.S Grade 3 |
A333 Grade 3 |
A334 Grade 3 |
A420 WPL3 |
A350 LF3 |
A516 |
A350 LF3 |
|
Low Temp C.S Grade 6 |
A333 Grade 6 |
A334 Grade 6 |
A420 WPL6 |
A350 LF2 |
A516 |
A350 LF2 |
Duplex Fittings
|
Grade |
Pipe |
Tube |
Fittings |
Plate |
Bar |
Forgings |
UNS No. |
|
Duplex 2205 |
A790 |
A789 |
A815 |
A240 |
A276/A479 |
A182 |
S31803/S32205 |
Nickel Fittings
|
Grade |
Pipe |
Tube |
Fittings |
Flanges |
Plate |
Bar |
Forgings |
UNS No. |
|
6 Moly & Alloy |
SB-312 |
|
|
SB-269 |
SB-688 |
SB-691 |
N08367 |
|
|
AL6XN |
SB-358 |
|
|
SB-270 |
|
|
|
|
|
Monel 400 |
SB-165 |
SB-165 |
|
SB-366 |
SB-127 |
SB-164 |
SB-564 |
N04400 |
|
|
SB-829 |
SB-163 |
|
|
|
QQ-N-281 |
|
|
|
|
SB-725 |
SB-730 |
|
|
|
|
|
|
|
|
SB-775 |
SB-751 |
|
|
|
|
|
|
|
Inconel 600 |
SB-167 |
SB-163 |
SB-366 |
SB-168 |
SB-166 |
SB-564 |
|
|
|
|
SB-829 |
SB-516 |
|
AMS-540 |
AMS-5665 |
AMS-5665 |
|
|
|
|
SB-517 |
SB-751 |
|
|
|
|
|
|
|
|
SB-775 |
AMS-5580 |
|
|
|
|
|
|
|
Inconel 625 |
SB-444 |
SB-444 |
SB-366 |
SB-443 |
SB-564 |
SB-564 |
N06625 |
|
|
|
SB-829 |
SB-829 |
|
AMS-5599 |
AMS-5666 |
AMS-5666 |
|
|
|
|
SB-775 |
SB-775 |
|
AMS-5869 |
AMS-5837 |
|
|
|
|
|
SB-705 |
SB-704 |
|
|
|
|
|
|
|
|
|
AMS-5581 |
|
|
|
|
|
|
|
Incoloy 800H |
SB-407 |
SB-407 |
SB-366 |
SB-409 |
SB-408 |
SB-564 |
N08810 |
|
|
|
SB-829 |
SB-829 |
|
AMS-5877 |
AMS-5766 |
AMS-5766 |
|
|
|
|
SB-514 |
SB-515 |
|
|
|
|
|
|
|
|
SB-775 |
SB-751 |
|
|
|
|
|
|
|
Incoloy 800Ht |
SB-407 |
SB-407 |
SB-366 |
SB-409 |
SB-408 |
SB-564 |
N08811 |
|
|
|
SB-829 |
SB-829 |
|
AMS-5877 |
AMS-5766 |
AMS-5766 |
|
|
|
|
SB-514 |
SB-515 |
|
|
|
|
|
|
|
|
SB-775 |
SB-751 |
|
|
|
|
|
|
|
Titanium Grade2 |
SB-337 |
SB-337 |
SB-366 |
SB-265 |
SB-348 |
SB-381 |
|
|
|
|
SB-338 |
SB-338 |
|
AMS-4902 |
F-67 |
|
|
|
|
|
|
|
|
|
AMS-4921 |
|
|
|
|
Hastelloy C276 |
SB-622 |
SB-622 |
SB-366 |
SB-575 |
SB-6574 |
SB-564 |
|
|
|
|
SB-619 |
SB-516 |
|
|
|
|
|
|
|
|
SB-775 |
SB-626 |
|
|
|
|
|
|
|
Stainless 254 SMO |
|
|
|
|
|
|
|
S31254 |
