2    X- AXIS

∙ X-axis travel                                                                       : 1,500 mm

∙ Rapid traverse of table                                                        : 30,000 mm/min

             ∙ Feed rate of table                                                                : 1~10,000mm/min

 3    Y- AXIS

             ∙ Y-axis travel (spindle head cross stroke)                               : 3,000 mm

             ∙ Rapid traverse of spindle head                                             : 30,000 mm/min

             ∙ Feed rate of spindle head                                                     : 1~10,000 mm/min

4    Z - AXIS

             ∙ Ram sectional dimensions [4 square]                                    : 300 mm

             ∙ Rapid traverse of ram                                                           : 20,000 mm/min

             ∙ Feed rate of ram                                                                  : 1~10,000 mm/min
