AJCE Hydraulic Hammer Breaker Backhoe and Skid Type
- Award
-
- Shipping
-
- Type of Freight AT,MT
- Modes of Transport CFR,CIF,EXW,FCA,FOB
- Products Shipped From Busan
- Payment
-
140+ Global Payments, trusted and secure payment provided by PayVerse.
Learn More
- Quantity
- MOQ : 1 Units
Detailed Description
>
* Breaking rocks and other materials for mining, road construction, and demolition.
* Durable parts made of genuine Korean material and heat treatment
* Auto-greasing channel built in
* Underwater hammering is available
* Standard accessories per unit are: chisel (2pcs), hyd. hose (2pcs), tool box, seal kit,
N2 gas tank with charging kit, working suit, and manual.
* Auto-greasing kit and Hardox bracket are optional.
* Standard wooden packing
* 3 weeks delivery time
* OEM is available
<400M Specification>
| Suitable Excavator | ton | 4~7 | |
| lb | 8962~15432 | ||
| Operating | Top Type | kg | 321 |
| lb | 706 | ||
| Box Type | kg | 325 | |
| Weight | lb | 715 | |
| Side Type | kg | 275 | |
| lb | 605 | ||
| Required Oil Flow | l/min | 40~70 | |
| gal/min | 10.6~18.5 | ||
| Setting Pressure | bar | 170 | |
| psi | 2418 | ||
| Operating Pressure | bar | 110~140 | |
| psi | 1565~1991 | ||
| Impact Energy | joule | 677 | |
| ft.lbs | 500 | ||
| kg.m | 70 | ||
| Impact Rate | bpm | 500~900 | |
| Hose Diameter | inch | ½ | |
| Noise Level | dB | 109 | |
| Tool Diameter | mm | 68 | |
| inch | 2.7 | ||
