AJCE Hydraulic Hammer Breaker Side Type
- Certification
-
- Award
-
- Shipping
-
- Type of Freight AT,MT
- Modes of Transport CFR,CIF,CIP,FCA,FOB
- Products Shipped From Busan
- Payment
-
140+ Global Payments, trusted and secure payment provided by PayVerse.
Learn More
- Quantity
- MOQ : 1 Units
Detailed Description
AJCE Hydraulic Hammer Breaker
* Breaking rocks and other materials for mining, road construction, and demolition.
* Durable parts made of genuine Korean materials and heat treatment
* Auto-greasing channel built in
* Underwater hammering is available
* Standard accessories per unit are: chisel (2pcs), hyd. hose (2pcs), tool box, seal kit,
N2 gas tank with charging kit, working suit, and manual.
* Auto-greasing kit and Hardox bracket are optional.
* Standard wooden packing
* 3 weeks delivery time
* OEM is available
* Side bracket type AS-1250M's specification
| Suitable Excavator | ton | 29~36 | |
| lb | 63934~79366 | ||
| Operating | Top Type | kg | 3151 |
| lb | 6944 | ||
| Box Type | kg | 2983 | |
| Weight | lb | 6575 | |
| Side Type | kg | 2735 | |
| lb | 6027 | ||
| Required Oil Flow | l/min | 180~250 | |
| gal/min | 47.5~66.1 | ||
| Setting Pressure | bar | 210 | |
| psi | 2987 | ||
| Operating Pressure | bar | 160~180 | |
| psi | 2276~2560 | ||
| Impact Energy | joule | 8812 | |
| ft.lbs | 6527 | ||
| kg.m | 904 | ||
| Impact Rate | bpm | 250~400 | |
| Hose Diameter | inch | 1¼ | |
| Noise Level | dB | 123 | |
| Tool Diameter | mm | 155 | |
| inch | 6.1 | ||
