Chemical Resistance Ball Valves Thread Type
- Award
-
- Shipping
-
- Modes of Transport EXW,FOB
- Payment
-
140+ Global Payments, trusted and secure payment provided by PayVerse.
Learn More
- Quantity
- MOQ : 1 Cartons
Detailed Description
BALL VALVE (THREAD TYPE)
TYPE : THREAD
MATERIALS : PP, PVDF, PVC, CPVC
O-RING : EPDM or FPM
STANDARD
JIS : 15mm - 50mm
FEATURES
- Full Bore Type
- Securing confidentiality by installing on STEM double O-RING
- High durability and convenience in manipulation
- Installing PTFE SEAL
- Enabling control for two-way flow
| NO | PARTS | MATERIALS |
| 1 | HANDLE CAP BOLT | SS41(ABS COATED) |
| 2 | HANDLE | PP |
| 3 | GLAND CAP | PP, PVDF, PVC, CPVC |
| 4 | STEM WASHER | PE |
| 5 | STEM | PP, PVDF, PVC, CPVC |
| 6 | STEM O-RING | EPDM, FPM |
| 7 | STEM RING | PE, EPDM |
| 8 | BODY CAP RING | PE |
| 9 | NIP SEAL | PTEE |
| 10 | BODY CAP | PP, PVDF, PVC, CPVC |
| 11 | BODY | PP, PVDF, PVC, CPVC |
| 12 | BALL | PP, PVDF, PVC, CPVC |
------------------------------------------------------------------------------------------------------------------------------
------------------------------------------------------------------------------------------------------------------------------
ASUNG PLASTIC VALVE CO., LTD / ASUNG CLEAN FLOW CO., LTD.
www.asungvalve.com
------------------------------------------------------------------------------------------------------------------------------
